Complex of continuous diagnostics
«CCD» series
Complex of continuous diagnostics ("CCD") intended for continuous diagnostics and detection of internal and external defects in a copper wire, a katanka, etc. in the course of their production. Pozvolyaetya to find in real time unacceptable external and internal defects, and also foreign particulates.
Complex of continuous diagnostics
for the one piece rolled wheel pair assembly
Comparison of the hardware
for the railway transport
one piece rolled wheel pairs
diagnostics
| № | Compared parameters | Standard hardware | «CCD» |
| 1. | Applied inspection method |
Ultrasonic and eddy current
|
Eddy current modified
|
| 2. | Flaw detection time, min | more60 | up to 10 |
| 3. | Testing reliability | about 70 % | more 90 % |
| 4. | Consumables |
In most cases, requires the use of immersion liquids
|
Not required |
| 5. |
Dependence on qualification of the NDT Inspector
|
Depends to a large extent
|
Independent |
Rails complex of continuous diagnostics
Comparison of the hardware
for the railway transport rails
diagnostics
| № | Compared parameters | Standard hardware | «CCD» |
|---|---|---|---|
| 1. | Applied inspection method | Ultrasonic | Eddy current modified |
| 2. | Permitted speed (km/h) | up to 60 | up to 120 |
| 3. |
Requirements for the moving means
|
Specialized trucks or
cars-laboratories
|
Can be installed on any type of railway equipment
|
| 4. | Testing reliability | about 70 % | more 90 % |
| 5. | Consumables |
In most cases, requires the use of immersion liquids
|
Not required |
Contact wire clamp
complex of continuous diagnostics
Comparison of the hardware
for the overhead wiring flaw detection
| № | Compared parameters | Standard hardware | «CCD» |
|
1. |
Applied inspection method |
Optical (television) | Eddy current modified |
| 2. | Detected defects |
Wear and breaking the rules of the hanging the contact wire.
|
Any kind of defects (cracks, inclusions) in the contact wire and connecting elements
|
| 3. | Permitted speed (km/h) | up to 60 |
On all operating speeds
|
| 4. |
Requirements for the moving means
|
Specialized cars-laboratories
|
Can be installed on any type of railway equipment
|
Copper overhead wire complex of continuous diagnostics
